Image Sensor:

• 1/2.9” Progressive Scan CMOS
• Shutter Speed: 1/3 to 1/10000 s
• Minimum Illumination: 0.005 Lux (color), 0 Lux with IR light
• Day/Night Mechanism: IR Cut Filter, switchable (Unified/Scheduled/Auto)

Lens:

• Motorized Varifocal Lens, 2.7-13.5 mm (5X Optical Zoom), F1.6 aperture
• Field of View (FOV): Horizontal (29.6°-102.0°), Vertical (16.8°-53.8°), Diagonal (34.1°-122.8°)
• DORI Distance: Detect (66-207 m), Observe (28-86 m), Recognize (13-41 m), Identify (7-21 m)
• Angle Adjustment: Pan (0° to 360°), Tilt (0° to 90°), Rotation (0° to 360°)

Illuminator:

• IR LED: 4 LEDs, 60m range, 850nm wavelength
• Control: Auto/Scheduled/Always on/Always off

Video:

• Max. Resolution: 2688 x 1520
• Main Stream: Up to 30fps, various resolutions
• Sub-Stream: Up to 30fps, lower resolutions
• Video Compression: H.265+/H.265/H.264+/H.264
• Bit Rate Control: CBR, VBR

Image:

• Settings: Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, etc.
• Enhancement: BLC, 3D DNR, HLC, SmartIR
• Wide Dynamic Range: 120 dB
• Privacy Mask: Up to 4 masks

Audio:

• Two-Way Audio, with input/output
• Compression: G.711 alaw, 64 Kbps
• Environment Noise Filtering

Network:

• Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
• ONVIF: Yes
• Simultaneous Live View: 3 main streams & 3 sub-streams
• Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

Alarm and Event Management:

• Smart Events: Intrusion, Line-Crossing, Region Entering/Exiting, Object Abandoned/Removal, Loitering, People, Vehicle, Abnormal Sound, Scene Change Detection
• Basic Events: Motion Detection (Enhanced with Human & Vehicle Classification), Video Tampering, Illegal Login
• Alarm Linkage: Memory Card Recording, Message Push, Audible Warning, Email Alarm, Upload Capture to FTP, Alarm Out Device

Interfaces:

• Network Interface: 1 RJ45 10/100M Ethernet Port, PoE
• Alarm: 1 Alarm In, 1 Alarm Out
• On-board Storage: MicroSD Card Slot, up to 512 GB
• Built-in Microphone

General:

• Operating Temperature: -30–60 °C
• Storage Temperature: -40–60 °C
• Humidity: 95% or less (non-condensing)
• Protection: IP67 Weatherproof, IK10 Vandal Proof
• Power Supply: 12V DC, PoE (802.3af/at)
• Dimensions: 10.1 × 3.9 × 4 in
• Certifications: CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF
